MIL-DTL-17587C(SH)
TABLE V. Qualification and comparison test schedule and sequence /1 - Continued.
Test
Inspection
Requirement
Verification
number
8B(3)
Electric cycling and mechanical position indicator operation
8B(4)
Manual cycling and mechanical position indicator operation
8B(5)
Anti-rolling verification
8C
Disconnect position:
8C(1)
Rack-in/rack-out position indicator operation
8C(2)
Cell switch operation
8C(3)
Manual cycling and mechanical position indicator operation
8C(4)
Anti-rolling verification
8D
Withdrawn position:
8D(1)
Manual cycling and mechanical position indicator operation
8D(2)
Anti-rolling verification
9
Circuit breaker temperature rise (pre-interruption at rated current)
Tests performed during circuit breaker temperature rise:
9A
Auxiliary switch rating
9B
Auxiliary switch temperature rise
9C
Secondary disconnecting device rating
9D
Secondary disconnecting device temperature rise
9E
Undervoltage release device temperature rise
10
Circuit breaker temperature rise (pre-interruption at 150% rated
current)
11
Dielectric strength (full voltage)
12
Insulation resistance (10-megohm threshold)
13
Short-time current duty cycle performance (withstand rating)
14
Interrupting current duty cycle performance
