MIL-DTL-17587C(SH)
TABLE V. Qualification and comparison test schedule and sequence /1 - Continued.
Test
Inspection
Requirement
Verification
number
See tests above
31
Attachment operational checks (same as test numbers 8A(2)
as noted
through 8A(2)(h) except performed in the normal
vertical/horizontal orientation circuit breakers with electronic
trip units only)
32
Dielectric strength (reduced voltage circuit breakers with
electronic trip units only)
33
Insulation resistance (1-megohm threshold circuit breakers with
electronic trip units only)
NOTE:
/1 Refer to the applicable circuit breaker individual specification sheet for additional test information and
requirements.
4.3 Conformance inspection.
4.3.1 Inspection. Each manufactured unit shall be subjected to the inspection specified in Table VI, unless
inspection sampling is otherwise specified (see 6.2).
4.3.2 Rejected units. If a unit is rejected, the contractor shall rework the unit to correct the defects and
resubmit the unit for inspection, as specified (see 6.2). Such units shall be separate from new units and shall be
clearly identified as a resubmitted unit for inspection. The contractor shall also determine if the identified defect is
likely to exist in other in-process and completed units, and inspect and disposition these units if appropriate.
TABLE VI. Conformance inspection.
Requirement
Test method
Item
Inspection
paragraph
paragraph
Dielectric strength
Circuit breakers
Abbreviated calibration
4.5.3 through
Attachments
Attachment operating characteristics
21
