TABLE XVI. Dielectric strength test points (circuit breaker poles and
ground) with circuit breaker closed.
Circuit breaker load side terminals on
Circuit breaker closed
cradle
Left pole
Center pole
Right pole
Circuit
Left pole
X
X
breaker line
side terminals
Center pole
X
on cradle
Right pole
X
Ground
X
X
4.5.10.3.1.2 Control wiring and ground used as test points.
4.5.10.3.1.2.1 Charging motor. Tie all charging motor leads together and apply 900 volts between lead bundle
and charging motor housing.
4.5.10.3.1.2.2 All other secondary disconnect control wiring. With the circuit breaker closed, the voltage shall
be applied between secondary disconnect control wiring of the same voltage rating and test points as marked with an
"X" in Table XVII.
TABLE XVII. Dielectric strength test points [secondary disconnect control wiring (excluding
charging motor), circuit breaker poles, and ground] with circuit breaker closed.
Circuit breaker terminals on cradle
Ground
Left pole
Center pole
Right pole
Secondary
disconnect
control wiring
of same voltage
rating /1
X
X
X
X
NOTE:
/1 Secondary disconnect control wiring leads shall be tied together and voltage applied between
the tied bundle and the points specified.
4.5.11 Insulation resistance.
4.5.11.1 Test equipment. Unless otherwise specified in the specification sheets, insulation resistance shall be
measured with a 500-volt insulation resistance testing device.
4.5.11.2 Test points and conditions. Insulation resistance shall be measured between the same test points and
4.5.11.3 Pass/fail criteria.
4.5.11.3.1 10-megohm threshold. The insulation resistance shall be greater than 10 megohms as specified in
Table V.
4.5.11.3.2 1-megohm threshold. The insulation resistance shall be greater than 1 megohm as specified in
Table V.
