MIL-DTL-17587C(SH)
4.5.7.3 Instantaneous. Circuit breakers shall be tested in accordance with Tables XIII and XIV.
TABLE XIII. Instantaneous pickup testing (electromechanical and electronic trip units) /1.
Trip status
Applied
Instantaneous
current
Left pole
Center pole
Right pole
pickup setting
/2
(amps)
Reqd
Actl
Reqd
Actl
Reqd
Actl
90% of
nominal
No trip
No trip
No trip
instantaneous
pickup setting
Min.
setting
110% of
nominal
Trip
Trip
Trip
instantaneous
pickup setting
90% of
nominal
No trip
No trip
No trip
instantaneous
pickup setting
Intmd.
setting
110% of
nominal
Trip
Trip
Trip
instantaneous
pickup setting
90% of
nominal
No trip
No trip
No trip
instantaneous
pickup setting
Max.
setting
110% of
nominal
Trip
Trip
Trip
instantaneous
pickup setting
NOTES:
/1 Short-time delay band and short-time delay pickup (STDPU) settings shall be set to maximum.
/2 Minimum, intermediate (or as close to middle as possible) and maximum instantaneous setting available on the
circuit breaker, as specified in the applicable specification sheet.
