MIL-PRF-83383/4F
TABLE I. Dash numbers and characteristics.
Tripping times from -54°C ±5°C to +71°C ±5°C
Dash
Current
(time in seconds)
number
rating
Percent rated current
(amperes)
200
400
1000
Min
Max
Min
Max
Min
Max
01
5.0
7
80
1.2
10
.3
1.2
02
7.5
11
80
2.4
13
.33
1.1
03
10.0
12
80
2.8
11
.42
1.3
04
15.0
13
80
1.7
10
.35
1.2
05
20.0
14
80
2.9
9.6
.4
1.3
06
25.0
15
80
2.6
10
.4
1.3
07
35.0
16
80
2.8
11
.35
1.3
08
40.0
16
80
2.6
10
.36
1.3
09
50.0
13
80
2.9
10
.4
1.25
10
60.0
13
80
2.4
16
.26
1.8
11
75.0
13
80
2.5
16
.26
1.8
12
80.0
14
80
2.7
12.5
.3
2
13
100.0
17
63
3.5
13
.35
1.9
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Weight: 2.250 pounds (1,022 grams), maximum.
Trip indication: See figure 1.
Terminals: See figures 1 and 2.
Auxiliary contact terminals:
Contact capacity at 28 V dc and 115 V ac, 400 Hz shall be 3 amperes resistive, 1.5 amperes
inductive, and 0.5 ampere lamp load.
Voltage rating: 115/200 V dc, 400 Hz.
Current ratings: See table I.
Tripping times: See table I.
Response time: 25 milliseconds.
4
