MIL-PRF-83383/4F
Current
B
Lock washer
Flat washer
Nut
A
C
rating
+.030
2/
3/
1/
amperes
-.000
5 to 25
.190-32UNC-2A
.500
.500
AN315-3R
MS35338-43
NAS1149F0332P
35 to 100
.250-28UNF-2A
.610
.610
AN315-4R
MS35338-44
NAS1149F0463P
1/ Part number is from National Aerospace Standard NASM315.
2/ Part number is from National Aerospace Standard NASM35338
3/ Part number is from National Aerospace Standard NAS1149.
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.015
0.38
.127
3.23
.500
12.70
2.526
64.16
.02
0.5
.163
4.14
.600
15.24
2.940
74.68
.030
0.76
.172
4.37
.610
15.49
3.250
82.55
.031
0.79
.183
4.65
.77
19.6
3.29
83.6
.050
1.27
.24
6.1
1.530
38.86
3.43
87.1
.07
1.8
.243
6.17
1.838
46.69
3.69
93.7
.135
3.43
.25
6.4
2.03
51.6
4.26
108.2
.150
3.81
.350
8.89
2.28
57.9
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ±.015 (0.38 mm).
FIGURE 1. Dimensions and configuration - Continued.
2
