MIL-PRF-55629/11E
Inches
mm
Ltr
Min
Max
Min
Max
A
1.985
2.015
50.42
51.18
B
1.645
1.675
41.78
42.55
C
.360
.390
9.14
9.91
D
---
2.265
---
57.53
E
.735
.765
18.67
19.43
F
1.205
1.235
30.61
31.37
G
---
.590
---
14.99
H
.675
.705
17.15
17.91
J
---
2.075
---
52.71
K
1.672
1.702
42.47
43.23
L
.030
.033
0.76
0.84
M
1.515
1.545
38.48
39.24
N
.215
.245
5.46
6.22
P
---
1.920
---
48.77
R
.110
.140
2.79
3.56
S
.360
.390
9.14
9.91
T
.245
.275
6.22
6.99
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .015 (0.38 mm).
4. Terminal screw, No. 8, .164-32UNC-2A, .187 .015 long, material: Brass, tin plated (ASTM-B545
or equivalent).
5. Lockwasher - split, No. 8 NASM35338-137 or equivalent.
6. Physical item marking of the load terminal is optional.
7. For configuration 2, a "G" has been added to the end of the dash number.
FIGURE 2. Dimensions and configurations (configuration 2) - Continued.
