MIL-PRF-55629/11E
Inches
mm
Ltr
Min
Max
Min
Max
A
1.969
2.031
50.01
51.59
B
1.629
1.691
41.38
42.95
C
1.019
1.081
25.88
27.46
D
1.189
1.251
30.20
31.78
E
2.219
2.281
56.36
57.94
F
.719
.781
18.26
19.84
G
.365
.385
9.27
9.78
H
1.099
1.161
27.91
29.49
J
.559 DIA
.621 DIA
14.20 DIA
15.77 DIA
K
.658
.722
16.71
18.34
L
---
1.850
---
46.99
M
1.529
1.591
38.84
40.41
N
.189
.251
4.80
6.38
P
.030
.035
0.76
.89
R
.099
.161
2.51
4.09
S
---
1.650
---
41.91
T
---
2.032
---
51.61
U
.209
.271
5.31
6.88
V
.349
.411
8.86
10.44
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .031 (0.79 mm).
4. Terminal screw, No. 8, .164-32UNC-2A, .187 .015 long, material: Brass, tin plated (ASTM-B545
or equivalent).
5. Lockwasher - split, No. 8 NASM35338-137 or equivalent.
6. Physical item marking of the words "LOAD" and "CB CONT OPEN" is optional.
FIGURE 1. Dimensions and configurations (configuration 1) Continued.
