MIL-PRF-55629/8F
Inches
mm
Ltr
Min
Max
Min
Max
A
1.985
2.015
50.42
51.18
B
1.645
1.675
41.78
42.55
C
.360
.390
9.14
9.91
D
---
.750
---
19.05
E
1.205
1.235
30.61
31.37
F
---
.590
---
14.99
G
675
.705
17.15
17.91
H
---
2.438
---
61.93
J
---
2.075
---
52.71
K
1.672
1.702
42.47
43.23
L
.019
.021
0.48
0.53
M
.030
.033
0.76
0.84
N
1.515
1.545
38.48
39.24
P
.110
.140
2.79
3.56
R
.215
.245
5.46
6.22
S
---
1.920
---
48.77
T
.245
.275
6.22
6.99
U
.360
.390
9.14
9.91
V
.095
.125
2.41
3.18
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .015 (0.38 mm).
4. Terminal screw, No. 8, .164-32UNC-2A, .187 .015 long, Material: Brass, tin plated (ASTM-B545 or
equivalent).
5. Lockwasher - split, No. 8 NASM35338-137 or equivalent.
6. Physical item marking of the words "LOAD" and "CB CONT OPEN" is optional.
7. For configuration 2, a "G" has been added to the end of the dash number.
FIGURE 2. Dimensions and configurations (configuration 2) - Continued.
