MIL-PRF-55629/8F
Inches
mm
Ltr
Min
Max
Min
Max
A
1.969
2.031
50.01
51.59
D
1.189
1.251
30.20
31.78
B
1.629
1.691
41.38
42.95
C
1.019
1.081
25.88
27.46
E
.719
.781
18.26
19.84
F
.344
.406
8.74
10,31
G
.559 DIA
.621 DIA
14.20 DIA
15.77 DIA
H
.659
.722
16.71
18.34
J
---
2.100
---
53.34
K
---
1.850
---
46.99
L
.189
.251
4.80
6.38
M
.030
.035
0.76
0.89
N
---
1.650
---
41.91
P
---
2.032
---
51.61
R
.099
.161
2.51
4.09
S
.019
.021
0.48
0.53
T
.349
.411
8.86
10.44
U
.059
.121
1.50
3.07
V
.209
.271
5.31
6.88
W
1.529
1.591
38.84
40.41
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .031 (0.79 mm).
4. Terminal screw, No. 8, .164-32UNC-2A, .187 .015 long, Material: Brass, tin plated (ASTM-B545 or
equivalent).
5. Lockwasher - split, No. 8 NASM35338-137 or equivalent.
6. Physical item marking of the words "LOAD and `CB CONT OPEN" is optional.
FIGURE 1. Dimensions and configurations (configuration 1) Continued.
2
