MIL-PRF-55629/4G
Inches
mm
Ltr
Min
Max
Min
Max
A
2.475
2.505
62.86
63.63
B
2.045
2.075
51.94
52.71
C
.205
.235
5.21
5.97
D
---
1.515
---
38.48
E
.735
.765
18.67
19.43
F
.167
.197
4.24
5.00
G
1.423
1.453
36.14
36.91
H
.535
.565
13.59
14.35
J
---
2.514
---
63.85
K
1.921
2.081
48.79
52.86
L
.266
.296
6.75
7.52
M
.019
.021
0.48
0.53
N
1.925
1.955
48.89
49.66
P
---
2.438
---
61.92
R
.125
.155
3.18
3.94
S
.245
.275
6.22
6.98
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .015 (0.38 mm).
4. Nut-hex: .190 - 32 UNF-2B .313/.303 across flats, .109 .010 thick. Material: Brass
terminal.
5. Captive washer nut assembly of brass nut, bronze washer, tin plated; or lockwasher, internal or
6. Washer, flat: .378/.368 O.D., .204/.190 I.D., .032 .005 thick. Material: Brass
(ASTM-B121/B121M or equivalent), tin plated (ASTM-B545 or equivalent), or phosphor bronze,
Composition (ASTM-B139/B139M or equivalent).
7. Auxiliary contact terminals shall provide for soldered connections and shall be located on the back
side of the circuit breaker (same surface as main terminals) otherwise location, style and design are
optional.
8. Lockwasher, Split: NASM35338-138 or equivalent.
9. Physical item marking of the words "LOAD" and "CB CONT OPEN" is optional.
10. For configuration 2, an "L" has been added to the end of the dash number.
FIGURE 2. Dimensions and configurations (configuration 2) - Continued.
