MIL-PRF-55629/4G
Inches
mm
Ltr
Min
Max
Min
Max
A
.149
.211
3.78
5.36
B
1.420
1.470
36.07
37.34
C
.359
.391
9.12
9.93
D
.719
.781
18.16
19.84
E
2.046
2.078
51.97
52.76
F
---
2.530
---
64.26
G
.187
.249
4.75
6.32
H
.109
.171
2.77
4.34
J
.249
.311
6.32
7.90
K
1.660
1.960
42.16
49.78
L
---
.427 R
---
10.85 R
M
.519
.699
13.18
17.53
N
---
2.800
---
71.12
P
---
2.340
---
59.44
R
1.989
2.051
50.52
52.09
S
---
2.553
---
64.85
T
1.469
1.531
37.31
38.89
U
.344
.406
8.74
10.31
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .031 (0.79 mm).
4. Nut-hex: .190 - 32 UNF-2B, .313/.303 across flats, .109 .010 thick. Material: Brass (ASTM-B121/B121M
5. Captive washer nut assembly of brass nut, bronze washer, tin plated; or lockwasher, internal or external
6. Washer, flat: .378/.368 O.D., .204/.190 I.D., .032 .005 thick.
7 Auxiliary contact terminals shall provide for soldered connections and shall be located on the back
side of the circuit breaker (same surface as main terminals) otherwise location, style and design are
optional.
9. Physical item marking of the words "LOAD" and "CB CONT OPEN" is optional.
FIGURE 1. Dimensions and configurations (configuration 1) Continued.
2
