MIL-PRF-83383/1F
TABLE I. Dash numbers and characteristics.
Tripping times from -54C 5C to +71C 5C
Dash
Current
(time in seconds)
number
rating
Percent rated current
(amperes)
200
400
1000
Min
Max
Min
Max
Min
Max
01
5.0
7
40
1.2
6.4
.3
1.2
02
7.5
11
40
2.4
6.8
.33
1.1
03
10.0
12
42
2.8
8.5
.42
1.05
04
15.0
13
45
1.7
8.3
.35
1.2
05
20.0
14
46
2.9
7.6
.4
1.15
06
25.0
15
50
2.6
8.7
.4
1.3
07
35.0
16
55
2.8
8.3
.35
1.3
08
40.0
16
55
2.9
9.2
.36
1.3
09
50.0
13
55
2.9
10
.4
1.25
10
60.0
13
60
2.6
13
.26
1.8
11
75.0
13
60
2.5
13
.26
1.8
12
80.0
14
60
2.7
12.5
.3
2
13
100.0
17
63
3.5
13
.35
1.9
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Weight:
5 to 25 amperes: 0.735 pound (334 grams), maximum.
35 to 50 amperes: 0.750 pound (341 grams), maximum.
60 to 100 amperes: 0.766 pound (348 grams), maximum.
Trip indication: See figure 1.
Terminals: See figures 1 and 2.
Voltage rating: 28 V dc or 115 V ac, 400 Hz.
Current ratings: See table I.
Tripping times: See table I.
Response time: 25 milliseconds, maximum.
