MIL-PRF-55629/6G
Inches
mm
Ltr
Min
Max
Min
Max
A
.149
.211
3.78
5.36
B
1.420
1.470
36.07
37.34
C
.359
.391
9.12
9.93
D
.719
.781
18.16
19.84
E
2.046
2.078
51.97
52.76
F
---
2.530
---
64.26
G
.187
.249
4.75
6.32
H
.109
.171
2.77
4.34
J
.249
.311
6.32
7.90
K
1.660
1.960
42.16
49.78
L
---
.427 R
---
10.84 R
M
.519
.699
12.95
17.75
N
---
2.800
---
71.12
P
---
2.340
---
59.44
R
2.000
2.040
50.80
51.82
S
---
2.553
---
64.85
T
2.205
2.285
56.01
58.04
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .031 (0.79 mm).
4. Nut-hex: .190 - 32 UNF-2B, .313/.303 across flats, .109 .010 thick. Material: Brass
(ASTM-B121/B121M or equivalent); tin plated (ASTM-B545 or equivalent); or stainless steel, for
each terminal.
5. Captive washer nut assembly of brass nut, bronze washer, tin plated; or lockwasher, internal or
6. Washer, flat: .378/.368 O.D., .204/.190 I.D., .032 .005 thick. Material: Brass
(ASTM-B121/B121M or equivalent), tin plated (ASTM-B545 or equivalent), or phosphor bronze,
composition (ASTM-B139/B139M or equivalent).
7. Auxiliary contact terminals shall provide for soldered connections and shall be located on the back
side of the circuit breaker (same surface as main terminals) otherwise location, style and design
are optional.
8. Lockwasher, split: NASM35338-138 or equivalent.
9. Physical item marking of the words "LOAD" and "CB CONT OPEN" is optional.
FIGURE 1. Dimensions and configurations (configuration 1) Continued.
