MIL-PRF-55629/5G
Inches
mm
Ltr
Min
Max
Min
Max
A
.149
.211
3.78
5.36
B
1.420
1.470
36.07
37.34
C
.359
.391
9.12
9.93
D
.719
.781
18.16
19.84
E
2.046
2.078
51.97
52.76
F
---
2.530
---
64.26
G
.187
.249
4.75
6.32
H
.109
.171
2.77
4.34
J
---
2.553
---
64.85
K
.249
.311
6.32
7.90
L
1.660
1.960
42.16
49.78
M
---
.427 R
---
10.84
N
.519
.699
13.18
17.75
P
1.940
2.100
49.28
53.34
R
2.205
2.285
56.01
58.04
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .031 (0.79 mm).
4. Nut-hex: .190 - 32 UNF-2B, .313/.303 across flats, .109 .010 thick. Material: Brass
(ASTM-B121/B121M or equivalent); tin plated (ASTM-B545 or equivalent); or stainless steel, for
each terminal.
5. Captive washer nut assembly of brass nut, bronze washer, tin plated; or lockwasher, internal or
6. Washer, flat: .378/.368 O.D., .204/.190 I.D., .032 .005 thick. Material: Brass
(ASTM-B121/B121M or equivalent), tin plated (ASTM-B545 or equivalent), or phosphor bronze,
composition (ASTM-B139/B139M or equivalent).
7. Lock washer, split: NASM35338-138 or equivalent.
8. Physical item marking of the load terminals is optional.
FIGURE 1. Dimensions and configurations (configuration 1) Continued.
