MIL-PRF-55629/1G
Inches
mm
Ltr
Min
Max
Min
Max
A
2.475
2.505
62.86
63.63
B
2.045
2.075
51.94
52.71
C
.205
.235
5.21
5.97
D
---
.750
---
19.05
E
.167
.197
4.24
5.00
F
1.423
1.453
36.14
36.91
G
.535
.565
13.59
14.35
H
1.921
2.081
48.79
52.86
J
---
2.514
---
63.85
K
.266
.296
6.76
7.52
L
1.925
1.955
48.90
49.66
M
.125
.155
3.18
3.94
N
.245
.275
6.22
6.98
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .015 (0.38 mm).
4. Nut-hex: (.2 - 65 amperes) .190 - 32 UNF-2B .313/.303 across flats, .109 .010 thick. (75 - 100
amperes) .250 - 28 UNF-2B .438 .016 across flats or .250 - 20 UNC-2B .375 .016 across flats.
Stainless steel, for each terminal.
5. Captive washer nut assembly of brass nut, bronze washer, tin plated; or lockwasher, internal or
MS35335-89 (75 -100 amperes) or equivalent. (Use of washers optional on 65 - 100 amperes
units.)
6. Washer, flat: (.2 - 50 amperes) .378/.368 O.D., .204/.190 I.D., .032 .005 thick. (65 100
amperes) .500 .016 O.D., .281 .016 I.D., .035 .005 thick. Material: Brass (ASTM-B121/B121M
or equivalent), tin plated (ASTM-B545 or equivalent), or phosphor bronze, composition
(ASTM-B139/B139M or equivalent).
7. Lockwasher, Split: (.2 - 65 amperes) NASM35338-138 or equivalent. (75 - 100 amperes)
NASM35338-139 or equivalent.
8. Physical item marking of load terminal optional.
9. For configuration 2, an "L" has been added to the end of the dash number.
FIGURE 2. Dimensions and configurations (configuration 2) - Continued.
4
