MIL-PRF-39019/1H
REQUIREMENTS:
Dimensions and configuration: See figure 1 and note 11.
Weight: For reference only, approximately 50 grams.
Mounting hardware: See figure 1.
Terminals: See figure 1.
Voltage and frequency rating: 50 V dc, maximum and 240 V ac, maximum at 60 Hz and 400 Hz.
High inrush: 800 percent at 60 Hz and dc, 1,400 percent at 400 Hz (see table I).
Current rating: See table I.
Circuit diagram: See figure 1.
Time delay: See table I.
Resistance or impedance: See table I.
Part or Identifying Number (PIN): The PIN shall be M39019/01-(dash number taken from table I) (e.g.,
M39019/01-200, M39019/01-200S).
Cross reference: See table II.
TABLE I. Circuit breaker dash numbers and applicable characteristics.
Dash number 1/
Current
Time delay
Resistance or impedance
rating
(ohms - max) 2/
(amps)
Standard
High
DC
60 Hz
400 Hz
delay
inrush
200
300
0.05
A
680.0
690.0
710.0
201
301
0.05
B
680.0
690.0
710.0
202
---
0.05
C
680.0
690.0
710.0
203
302
0.1
A
150.0
170.0
180.0
204
303
0.1
B
150.0
170.0
180.0
205
---
0.1
C
150.0
170.0
180.0
206
304
0.25
A
20.0
26.0
27.0
207
305
0.25
B
20.0
26.0
27.0
208
---
0.25
C
20.0
26.0
27.0
209
306
0.5
A
5.4
6.0
6.6
210
307
0.5
B
5.4
6.0
6.6
211
---
0.5
C
5.4
6.0
6.6
212
308
0.75
A
2.5
2.7
2.8
213
309
0.75
B
2.5
2.7
2.8
214
---
0.75
C
2.5
2.7
2.8
215
310
1.0
A
1.35
1.5
1.61
