INCH-POUND
MIL-DTL-23928/1E
2 February 2013
SUPERSEDING
MIL-DTL-23928/1D
22 October 2010
DETAIL SPECIFICATION SHEET
PANEL, ELECTRICAL, 125 VOLTS, POWER DISTRIBUTION FOR ALB-1 AND NLB-1
CIRCUIT BREAKERS, 4-24 CIRCUITS, DRIPPROOF, THREE PHASE FEED, SINGLE
AND THREE PHASE LOADS, TOTALLY ENCLOSED AND WATERTIGHT
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-DTL-23928.
Note: Dripshield required for dripproof enclosure only.
FIGURE 1. Distribution panel for ALB-1 and NLB-1 circuit breakers, totally
enclosed and dripproof enclosure (typical).
AMSC N/A
FSC 5925
