MIL-C-55629/16C
Inches
mm
Ltr
Min
Max
Min
Max
A
2.062 2.082
52.37
52.88
B
1.016 1.036
25.81
26.31
C
.285
---
7.24
---
D
2.740 2.760
69.60
70.10
E
.530
.550
13.46
13.97
F
---
.730
---
18.54
G
.380
.400
9.65
10.16
H
2.245 2.265
57.02
57.53
J
1.115 1.135
28.32
28.83
K
2.600 2.620
66.04
66.55
L
.210
.230
5.33
5.84
M
1.210 1.230
30.73
31.24
N
.115
.135
2.92
3.43
P
.475
.495
12.07
12.57
R
2.146 2.166
54.51
55.02
S
5.790 5.810
147.06
147.57
T
4.740 4.760
120.47
120.90
U
2.365 2.385
60.07
60.58
V
.210
.230
5.33
5.84
W
4.834 4.854
122.78
123.29
X
.190
.210
4.83
5.33
Y
1.016 1.036
25.81
26.31
Z
1.016 1.036
25.81
26.31
AA
.508
.518
12.90
13.16
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ±.010 inch (.254 mm).
4. Configuration optional providing overall dimension are not exceeded.
5. Screw (0 - 50 amperes) .190-32 UNF-2A.
(51 - 100 amperes) .250-20 UNC-2A.
6. Lockwasher, internal or external tooth, for 0-50 amperes, NASM35333-107 or MS35335-88
and for 51 - 100 amperes, NASM35333-108 or MS35335-89, or equivalent.
7. Mounting slot: Clearance for .164-32 UNC screw, 4 places.
FIGURE 1. Dimensions and configurations - Continued.
